SPI Bus Signal Analysis Function
2
2.6 Communication Commands
Command Function Page
SPI Analyze Group
:SEARch:SPI? Queries all settings related to the SPI analysis function. 2-22
:SEARch:SPI:ANALyze? Queries all settings related to the SPI analysis execution. 2-22
:SEARch:SPI:ANALyze:ABORt Aborts the SPI analysis execution. 2-22
:SEARch:SPI:ANALyze:EXECute Executes the SPI analysis. 2-22
:SEARch:SPI:ANALyze:SETup? Queries all settings related to the SPI analysis conditions. 2-22
:SEARch:SPI:ANALyze:SETup:BITorder Sets the bit order of the display of the SPI analysis data results or
queries the current setting. 2-22
:SEARch:SPI:ANALyze:SETup:CLOCk? Queries all settings related to the clock channel of the SPI analysis
conditions. 2-23
:SEARch:SPI:ANALyze:SETup:CLOCk:HYSTeresis
Sets the clock channel hysteresis of the SPI analysis conditions or queries
the current setting. 2-23
:SEARch:SPI:ANALyze:SETup:CLOCk:LEVel
Sets the clock channel level of the SPI analysis conditions or queries the
current setting. 2-23
:SEARch:SPI:ANALyze:SETup:CLOCk:POLarity
Sets the edge of the clock channel to be analyzed of the SPI analysis
conditions or queries the current setting. 2-23
:SEARch:SPI:ANALyze:SETup:CS? Queries all settings related to the CS signal of the SPI analysis conditions. 2-23
:SEARch:SPI:ANALyze:SETup:CS:CHANnel4?
Queries all settings related to CH4 of the SPI analysis CS signal conditions.2-23
:SEARch:SPI:ANALyze:SETup:CS:CHANnel4:LEVel
Sets the level of CH4 of the SPI analysis CS signal conditions. 2-23
:SEARch:SPI:ANALyze:SETup:CS:CHANnel4:MODE
Sets whether to handle CH4 as a CS signal (ON/OFF) in the SPI analysis
conditions or queries the current setting. 2-23
:SEARch:SPI:ANALyze:SETup:CS:ESTate Sets the enable state of the CS signal of the SPI analysis conditions or
queries the current setting. 2-24
:SEARch:SPI:ANALyze:SETup:DATA<x>? Queries all settings related to the data channel of the SPI analysis
conditions. 2-24
:SEARch:SPI:ANALyze:SETup:DATA<x>:LEVel
Sets the threshold level of the data channel of the SPI analysis conditions or
queries the current setting. 2-24
:SEARch:SPI:ANALyze:SETup:DATA<x>:MODE
Enables or disables the data channel (ON/OFF) of the SPI analysis
conditions or queries the current setting. 2-24
:SEARch:SPI:ANALyze:SETup:MPOSition Sets the reference position when the SPI reference position is set to
manual or queries the current setting. 2-24
:SEARch:SPI:ANALyze:SETup:RPOint Sets the SPI analysis reference position to the trigger position or manual
or queries the current setting. 2-24
:SEARch:SPI:LIST? Outputs one byte of SPI analysis result as a character string. 2-24
:SEARch:SPI:SEARch? Queries all settings related to the SPI analysis result search. 2-24
:SEARch:SPI:SEARch:DATA? Queries all settings related to the Data search of the SPI analysis results. 2-25
:SEARch:SPI:SEARch:DATA:BYTE Sets the number of data bytes to be searched for the Data search of the
SPI analysis results. 2-25
:SEARch:SPI:SEARch:DATA:HEXa<x> Sets the Data search pattern of the SPI analysis results in hexadecimals. 2-25
:SEARch:SPI:SEARch:DATA:PATTern<x> Sets the Data search pattern of the SPI analysis results in binary or queries
the current setting. 2-25
:SEARch:SPI:SEARch:NEXT? Performs the SPI analysis result search after the current byte and returns
the search position. 2-25
