2-26
IM 701610-61E
:SEARch:TYPE
Function Sets the search type or queries the current
setting.
Syntax :SEARch:TYPE {SPATtern|WIDTh|EDGE|
PPATtern|ASCRoll|I2CBus|SPIBus}
:SEARch:TYPE?
Example :SEARCH:TYPE SPIBUS
:SEARCH:TYPE? -> :SEARCH:TYPE SPIBUS
2.6 Communication Commands
SPI File Group
Commands in the SPI File group can be used to make the same settings, inquiries, and executions as when the
SPI bus menu under the FILE key on the front panel is used.
:FILE :
SAVE
:
SPI
:
ABORt
EXECute
?
;
;
:FILE:SAVE:SPI[:EXECute]
Function Executes the store operation of SPI analysis
results. This is an overlap command.
Syntax :FILE:SAVE:SPI[:EXECute]
Example :FILE:SAVE:SPI:EXECUTE
:FILE:SAVE:SPI:ABORt
Function Aborts the store operation of SPI analysis results.
Syntax :FILE:SAVE:SPI:ABORt
Example :FILE:SAVE:SPI:ABORT
To Next Page
