4-20
IM DL350E-17EN
4.1 List of Commands
Command Function page
:MATH<x>[:BINary]:{CHANnel
<x>[:SCHannel<x>]|MATH<x>}
[:THReshold]
Sets or queries the threshold level of the specified channel for binary
computations.
4-124
:MATH<x>:DISPlay
Sets or queries whether computations will be performed. 4-124
:MATH<x>:ESHift:{CHANnel<x>[:SC
Hannel<x>]|MATH<x>}[:COUNt]
Sets or queries the amount of phase shift in the Shift computation when an
external clock is used.
4-124
:MATH<x>:LABel
Sets or queries a computed waveform label. 4-124
:MATH<x>:MEAN:NUMBer
Sets or queries the value n of the moving average (MEAN). 4-124
:MATH<x>:MODE
Sets or queries the computation mode on/off state. 4-124
:MATH<x>:MREFerence
Sets or queries the computation range. 4-124
:MATH<x>:OPERation
Sets or queries the computation type. 4-125
:MATH<x>:SCALe?
Queries all scaling settings. 4-125
:MATH<x>:SCALe:MODE
Sets or queries a scale mode. 4-125
:MATH<x>:SCALe:VALue
Sets or queries a set of upper and lower limits for manual scaling. 4-125
:MATH<x>:SHIFt:{CHANnel<x>[:SCH
annel<x>]|MATH<x>}[:TIME]
Sets or queries the amount of phase shift in the Shift computation when the
internal clock is used.
4-125
:MATH<x>:SOURce<x>
Sets or queries a sub channel’s computation type. 4-125
:MATH<x>:UNIT
Sets or queries a unit that is attached to computation results. 4-125
MEASure Group
:MEASure?
Queries all the settings for automated measurement of waveform
parameters.
4-126
:MEASure:{CHANnel<x1>[:SCHannel
<x2>]|MATH<x3>}?
Sets or queries whether all the waveform parameters (measurement items)
of the specified channel are ON or OFF.
4-126
:MEASure:{CHANnel<x1>[:SCHannel
<x2>]|MATH<x3>}:ALL
Sets all the measurement items of the specified channel to ON or OFF. 4-126
:MEASure:{CHANnel<x1>[:SCHanne
l<x2>]|MATH<x3>}:CDEStination
(CopyDestination)
Sets or queries whether the copy destination channel is ON or OFF for when
parameters (measurement items) are copied between channels.
4-126
:MEASure:{CHANnel<x1>[:SCHannel
<x2>]|MATH<x3>}:COPY
Copies all the measurement item ON/OFF settings from one specified
channel to another specified channel.
4-126
:MEASure:{CHANnel<x1>[:SCHannel
<x2>]|MATH<x3>}:DELay?
Queries all delay settings. 4-126
:MEASure:{CHANnel<x1>[:SCHannel
<x2>]|MATH<x3>}:DELay:COUNt?
Queries the statistics count of the delay between channels. 4-127
:MEASure:{CHANnel<x1>[:SCHannel
<x2>]|MATH<x3>}:DELay:{MAXimum|
MEAN|MINimum|SDEViation}?
Queries a statistic of the delay between channels. 4-127
:MEASure:{CHANnel<x1>[:SCHannel
<x2>]|MATH<x3>}:DELay:MEASure?
Queries all the settings for a source waveform for measuring the delay
between channels of a waveform.
4-127
:MEASure:{CHANnel<x1>[:SCHannel
<x2>]|MATH<x3>}:DELay:MEASure:C
OUNt
Sets or queries the number of edges at which delay between channels will
be measured for a waveform.
4-127
:MEASure:{CHANnel<x1>[:SCHannel
<x2>]|MATH<x3>}:DELay:MEASure:S
LOPe
Sets or queries a source waveform slope that will be used to measure delay
between channels for a waveform.
4-127
:MEASure:{CHANnel<x1>[:SCHanne
l<x2>]|MATH<x3>}:DELay:REFeren
ce?
Queries all reference waveform settings used to measure the delay between
channels for the specified waveform.
4-128
:MEASure:{CHANnel<x1>[:SCHannel
<x2>]|MATH<x3>}:DELay:REFerence
:COUNt
Sets or queries the edge detection count of the reference waveform used to
measure the delay between channels for the specified waveform.
4-128
:MEASure:{CHANnel<x1>[:SCHannel
<x2>]|MATH<x3>}:DELay:REFerence
:LOGic:BIT
Sets or queries the bit of the reference waveform trace used to measure the
delay between channels for a waveform.
4-128
:MEASure:{CHANnel<x1>[:SCHannel
<x2>]|MATH<x3>}:DELay:REFerence
:SLOPe
Sets or queries the edge detection slope of the reference waveform used to
measure the delay between channels for the specified waveform.
4-128
:MEASure:{CHANnel<x1>[:SCHannel
<x2>]|MATH<x3>}:DELay:REFerence
:SOURce
Sets or queries whether to set the reference point for measuring the delay
between channels for a waveform to a trigger point or to a waveform.
4-129
:MEASure:{CHANnel<x1>[:SCHannel
<x2>]|MATH<x3>}:DELay:REFerence
:TRACe
Sets or queries the reference waveform trace used to measure the delay
between channels for a waveform.
4-129
