4.1 List of Commands
Command Function page
:MEASure:{CHANnel<x1>[:SCHannel
<x2>]|MATH<x3>}:DELay:STATe
Sets or queries the display format of the delay parameters of the specified
channel.
4-129
:MEASure:{CHANnel<x1>[:SCHannel
<x2>]|MATH<x3>}:DELay:VALue?
Queries a measured delay value of the specified waveforms parameter. 4-129
:MEASure:{CHANnel<x1>[:SCHannel
<x2>]|MATH<x3>}:DPRoximal?
Queries all distal, mesial, and proximal settings. 4-130
:MEASure:{CHANnel<x1>[:SCHannel
<x2>]|MATH<x3>}:DPRoximal:MODE
Sets or queries the distal, mesial, and proximal point mode setting. 4-130
:MEASure:{CHANnel<x1>[:SCHannel
<x2>]|MATH<x3>}:DPRoximal:PERCe
nt
Sets or queries the distal, mesial, and proximal points as percentages. 4-130
:MEASure:{CHANnel<x1>[:SCHannel
<x2>]|MATH<x3>}:DPRoximal:UNIT
Sets or queries the distal, mesial, and proximal points. 4-130
:MEASure:{CHANnel<x1>[:SCHannel
<x2>]|MATH<x3>}:METHod
Sets or queries the modes of a set of high and low points (rising-time and
falling-time measurement references).
4-130
:MEASure:{CHANnel<x1>[:SCHannel
<x2>]|MATH<x3>}:<Parameter>?
Queries the setting of a waveform parameter (measurement item). 4-131
:MEASure:{CHANnel<x1>[:SCHannel
<x2>]|MATH<x3>}:<Parameter>:COU
Nt?
Queries the count of measured values for cyclic statistical processing of a
waveform parameter.
4-131
:MEASure:{CHANnel<x1>[:SCHannel
<x2>]|MATH<x3>}:<Parameter>:{MA
Ximum|MEAN|MINimum|SDEViation}?
Queries a cyclic statistical processing value of a waveform parameter. 4-131
:MEASure:{CHANnel<x1>[:SCHannel
<x2>]|MATH<x3>}:<Parameter>:STA
Te
Sets or queries whether the specified waveform’s waveform parameter
(measurement item) is ON or OFF.
4-131
:MEASure:{CHANnel<x1>[:SCHannel
<x2>]|MATH<x3>}:<Parameter>:VAL
ue?
Queries the measured value of a waveform parameter. 4-132
:MEASure:{XY<x>}?
Queries all the settings for automated measurement of X-Y waveform
parameters.
4-132
:MEASure:{XY<x>}:<Parameter>?
Queries the setting of a X-Y waveform parameter (measurement item). 4-132
:MEASure:{XY<x>}:<Parameter>:CO
UNt?
Queries the count of measured values for cyclic statistical processing of a
X-Y waveform parameter.
4-132
:MEASure:{XY<x>}:<Parameter>:{
MAXimum|MEAN|MINimum|SDEViati
on}?
Queries a cyclic statistical processing value of a X-Y waveform parameter. 4-132
:MEASure:{XY<x>}:<Parameter>:ST
ATe
Sets or queries whether the specified X-Y waveform’s waveform parameter
(measurement item) is ON or OFF.
4-132
:MEASure:{XY<x>}:<Parameter>:VA
Lue?
Queries the measured value of a X-Y waveform parameter. 4-133
:MEASure:CHANnel<x1>:BIT<x2>:A
LL
Sets the specified bit of the specified channel to on or off at once. 4-133
:MEASure:CHANnel<x1>:BIT<x2>:CD
EStination
Sets or queries whether the copy destination channel is ON or OFF for when
parameter measurement items are copied between channels or bits.
4-133
:MEASure:CHANnel<x1>:BIT<x2>:CO
PY
Copies the on/off setting of the specified bit of the specified channel to
another specified channel.
4-133
:MEASure:CHANnel<x1>:BIT<x2>:DE
Lay?
Queries all settings related to the delay of the specified bit of the specified
channel on a logic module.
4-133
:MEASure:CHANnel<x1>:BIT<x2>:DE
Lay:COUNt?
Queries the statistics count of the delay of the specified bit of the specified
channel.
4-133
:MEASure:CHANnel<x1>:BIT<x2>:DE
Lay:{MAXimum|MEAN|MINimum|SDEVi
ation}?
Queries the statistical value of the delay of the specified bit of the specified
channel.
4-134
:MEASure:CHANnel<x1>:BIT<x2>:DE
Lay:MEASure?
Queries all settings related to the source waveform used to measure the
delay of the specified bit of the specified channel on a logic module.
4-134
:MEASure:CHANnel<x1>:BIT<x2>:DE
Lay:MEASure:COUNt
Sets or queries the edge detection count of the source waveform used to
measure the delay of the specified bit of the specified channel.
4-134
:MEASure:CHANnel<x1>:BIT<x2>:DE
Lay:MEASure:SLOPe
Sets or queries the edge polarity of the source waveform used to measure
the delay of the specified bit of the specified channel.
4-134
:MEASure:CHANnel<x1>:BIT<x2>:DE
Lay:REFerence?
Queries all settings related to the reference waveform used to measure the
delay of the specified bit of the specified channel on a logic module.
4-134
:MEASure:CHANnel<x1>:BIT<x2>:DE
Lay:REFerence:COUNt
Sets or queries the edge detection count of the reference waveform used to
measure the delay of the specified bit of the specified channel.
4-134
