YOKOGAWA DL350 User Manual

4-22
IM DL350E-17EN
4.1 List of Commands
Command Function page
:MEASure:CHANnel<x1>:BIT<x2>:DE
Lay:REFerence:LOGic:BIT
Sets or queries the reference waveform bit used to measure the delay of the
specified bit of the specified channel.
4-135
:MEASure:CHANnel<x1>:BIT<x2>:DE
Lay:REFerence:SLOPe
Sets or queries the edge polarity of the reference waveform used to measure
the delay of the specified bit of the specified channel.
4-135
:MEASure:CHANnel<x1>:BIT<x2>:DE
Lay:REFerence:SOURce
Sets or queries whether to set the reference for measuring the delay of the
specified bit of the specified channel to a trigger point or to a waveform.
4-135
:MEASure:CHANnel<x1>:BIT<x2>:DE
Lay:REFerence:TRACe
Sets or queries the reference waveform trace used to measure the delay of
the specified bit of the specified channel.
4-135
:MEASure:CHANnel<x1>:BIT<x2>:DE
Lay:STATe
Sets or queries the display format of the delay of the specified bit of the
specified channel.
4-135
:MEASure:CHANnel<x1>:BIT<x2>:DE
Lay:VALue?
Queries the delay measurement result of the specified bit of the specified
channel.
4-136
:MEASure:CHANnel<x1>:BIT<x2>:<P
arameter>?
Queries all settings related to the waveform parameter of the specified bit of
the specified channel on a logic module.
4-136
:MEASure:CHANnel<x1>:BIT<x2>:<P
arameter>:{MAXimum|MEAN|MINimum
|SDEViation}?
Queries the waveform parameter statistics value of the specified bit of the
specified channel.
4-136
:MEASure:CHANnel<x1>:BIT<x2>:<P
arameter>:COUNt?
Queries the waveform parameter statistics count of the specified bit of the
specified channel.
4-136
:MEASure:CHANnel<x1>:BIT<x2>:<P
arameter>:STATe
Sets or queries the on/off state of the waveform parameter of the specified
bit of the specified channel.
4-136
:MEASure:CHANnel<x1>:BIT<x2>:<P
arameter>:VALue?
Queries the measured waveform parameter value of the specified bit of the
specified channel.
4-136
:MEASure:CYCLe?
Queries all cycle statistics settings. 4-137
:MEASure:CYCLe:ABORt
Aborts cyclic statistical processing. 4-137
:MEASure:CYCLe:EXECute
Executes cyclic statistical processing. 4-137
:MEASure:CYCLe:LOGic:BIT
Sets or queries the cycle trace bit of cycle statistics. 4-137
:MEASure:CYCLe:TRACe
Sets or queries the cycle trace of cycle statistics. 4-137
:MEASure:HISTory:ABORt
Aborts the history statistical processing of history waveforms. 4-137
:MEASure:HISTory:EXECute
Executes the history statistical processing of history waveforms. 4-137
:MEASure:MODE
Sets or queries the type of statistical processing for the automatically
measured values of waveform parameters.
4-137
:MEASure:ONECycle
Sets or queries whether one cycle mode is ON or OFF. 4-137
:MEASure:TRANge (Time Range)
Sets or queries the waveform parameter measurement range. 4-137
:MEASure:WAIT?
Waits for the completion of measurement with a timeout period. 4-137
MONitor Group
:MONitor:ASENd?
Sends the numeric monitor data (in ASCII format) of all channels. 4-138
:MONitor:ASENd:CHANnel<x1>[:SCH
annel<x2>]?
Sends the numeric monitor data (in ASCII format) of the specified channel. 4-138
:MONitor:BITS:CHANnel<x1>[:SCHa
nnel<x2>]?
Queries the effective bit length of the specified channel’s data. 4-138
:MONitor:BYTeorder
Sets or queries the transmission byte order for data formats that are 2 bytes
or longer.
4-138
:MONitor:FORMat:CHANnel<x1>[:SC
Hannel<x2>]
Sets or queries the transmission data format. 4-138
:MONitor:GAIN:CHANnel<x1>[:SCHa
nnel<x2>]?
Queries the gain that is used when the specified channel’s numeric monitor
data is converted to a physical value.
4-138
:MONitor:LATCh:ASENd?
Sends the numeric monitor data (in ASCII format) of all channels when you
execute the latch command.
4-139
:MONitor:LATCh:ASENd:CHANnel<x1
>[:SCHannel<x2>]?
Sends the numeric monitor data (in ASCII format) of the specified channel
when you execute the latch command.
4-139
:MONitor:LATCh:EXECute
Latches monitor data and alarm data. 4-139
:MONitor:LATCh:SEND:{ALL|CHANne
l<x1>[:SCHannel<x2>]}?
Sends numeric monitor data when you execute the latch command. 4-139
:MONitor:OFFSet:CHANnel<x1>[:SC
Hannel<x2>]?
Queries the offset that is used when the specified channel’s numeric monitor
data is converted to a physical value.
4-139
:MONitor:RANGe:CHANnel<x1>[:SCH
annel<x2>]?
Queries the range that is used when the specified channel’s numeric monitor
data is converted to a physical value.
4-139
:MONitor:SEND:ALL?
Sends the numeric monitor data (in binary format) of the specified channel. 4-139
:MONitor:SEND:CHANnel<x1>[:SCHa
nnel<x2>]?
Sends the numeric monitor data (in binary format) of the specified channel. 4-139
:MONitor:VERBose
Set whether to include labels and units in the response to the
MONitor:ASENd? command.
4-139
