Yokogawa DX Serial Driver
Address Descriptions
Address specifications vary depending on the model in use. Select a link from the following list to obtain
specific address information for the model of interest.
DX102 Addressing
DX104 Addressing
DX106 Addressing
DX112 Addressing
DX204 Addressing
DX208 Addressing
DX210 Addressing
DX220 Addressing
DX230 Addressing
MV100 Addressing
MV200 Addressing
DX102 Addressing
The driver supports the following addresses for this device. The default data type for each address type is
shown in bold.
Measured Channels
Address Type Format Range Data Type Access
Process Value of Channel CHxx or CHxx.PV 01-02 Double, Float Read Only
Alarm Summary of Channel CHxx.Alarm 01-02 Short, Word, Byte Read Only
Alarm Level1 Status of Channel CHxx.Alarm1 01-02 Short, Word, Byte Read Only
Alarm Level2 Status of Channel CHxx.Alarm2 01-02 Short, Word, Byte Read Only
Alarm Level3 Status of Channel CHxx.Alarm3 01-02 Short, Word, Byte Read Only
Alarm Level4 Status of Channel CHxx.Alarm4 01-02 Short, Word, Byte Read Only
Set and Read Level1 Alarm Setpoint CHxx.ASP1 01-02 Double, Float Read/Write
Set and Read Level2 Alarm Setpoint CHxx.ASP2 01-02 Double, Float Read/Write
Set and Read Level3 Alarm Setpoint CHxx.ASP3 01-02 Double, Float Read/Write
Set and Read Level4 Alarm Setpoint CHxx.ASP4 01-02 Double, Float Read/Write
Upper Scale Value of Channel* CHxx.scale_Hi 01-02 Double, Float Read Only
Lower Scale Value of Channel* CHxx.scale_Lo 01-02 Double, Float Read Only
Unit String of Channel* CHxx.unit 01-02 String Read Only
Tagname of Channel* CHxx.tag 01-02 String Read Only
Status of Channel* CHxx.status 01-02 String Read Only
Lowest Measuring Channel* CH.Low Short, Word, Byte Read Only
Highest Measuring Channel* CH.High Short, Word, Byte Read Only
Math Channels
