<4. COMMISSIONING OF pH/ORP>
4-2
IM 12A01A02-01E 8th Edition : Oct. 01, 2015-00
Table 4.1 Menu Structure and Default Values in “Commissioning”
Parameter Ref. sect.
Sensor setup Sensor type 4.1
Measurement setup
Measurement 4.2.1
Temperature setting
Temp. element 4.2.2
Temp. compensation Compensation 4.2.3
Reference temp.
Process Temp. Compensation
Calibration settings pH settings Zero and Slope units 4.2.4
Limits and timing
Buffers (select set)
Zero/Slope/ITP
Auto correct (Zero, Slope)
ORP settings
rH settings
Limit and timing
Zero/Slope
Impedance settings 4.2.5
Concentration Unit 4.2.6
Sensor diag. settings Input 1 imp.: 4.2.7
FINE
Input 2 imp.:
Process time
Heat cycle:
Dene heat cycle
Output setup mA 4.3
Output
Process parameter
Setup
Linear
0 % value
100% value
Table
Burn
Damping time
Simulate Simulation perc.
Congure Hold
Error conguration 4.4
Logbook conguration 4.5
Advanced setup Settings 4.6.1
Tag 4.6.2
Passwords 4.6.3
Date/Time 4.6.4
Communication 4.6.5
HART
PH201G
Factory setup 4.6.6
Display setup Main display (Dual display, Individual display) 4.7.1
Trend 4.7.2
Auto Return 4.7.3
Adjust contrast 4.7.4
MONITOR display 4.7.5
Calculated data setup Function 4.8
NOTE
All the parameters for the quick setup (underlined ones in Table 4.1) are crucial for measurement.
If you change any of them, other parameters may be initialized. For the parameters that may
initialize other values, see Appendix 1.
