28
IM MY600-01EN
Number of measurements when a new battery is
used (measurement of 5 s, pause of 25 s)
Measurement
condition
Test resistor Number of measurements
Insulation
resistance
50V 0.050MΩ Approx. 2000 times or more
100V 0.100MΩ Approx. 1600 times or more
125V 0.125MΩ Approx. 1600 times or more
250V 0.25MΩ Approx. 1300 times or more
500V 0.5MΩ Approx. 1300 times or more
1000V 1MΩ Approx. 700 times or more
Low-resistance
measurement
1Ω Approx. 1400 times or more
* When using alkaline batteries with the backlight turned off. With
continuity buzzer set to off for low-resistance measurement
The number of measurements varies depending on the
operating conditions. Use the figures above as a guideline.
External Dimensions
156
97
46
Unit: mm
Unless otherwise specified,
tolerances are ±3% (however,
tolerances are ±0.3 mm when
below 10 mm).
