5. Voltage Measurement
WARNING
• Donotapplyavoltageexceedingtheoverloadprotection
voltage(600V)ofthisinstrument.
• Keepyourhandandfingersbehindtheprobebarrier
during a measurement.
• Verifythatthisinstrumentoperatesproperlyonaknown
power source before using the instrument or taking
actions based on the indicated result.
French
AVERTISSEMENT
• Nepasappliquerdetensionsupérieureàl’entrée
maximaleautorisée,600V,surl’appareil.
• Ayezvosdoigtsderrièrelabarrièrependantunemesure.
• Vérifierlebonfonctionnementd’unesourceconnue
avant de prendre des mesures à la suite de l’indication
de l’appareil.
Measurement Procedure
1.
Connect the probes as shown in the following figure.
Insert 98008 into the LINE terminal.
Insert 98009 into the EARTH terminal.
600 V MAX
Black (98009) Red (98008)
