33
IM MY600-01EN
98008 Line Probe with Remote Switch
Insulation cap
Barrier
1
Probe tip
Attached and used with 98008.
Probe tip (99013 long type)
The insulation cap is detachable. The
measurement category changes depending
on whether the insulation cap is attached.
For CAT III 600 V (
with insulation cap
)
For CAT II 1000 V (
without insulation cap
)
98009 Earth Probe Set
+
Cable with banana plugs on both ends (black)
Flat test bar
Barrier
1
Alligator clip
Barrier
1
L-shaped
banana plug
CAT III 600 V (with alligator clip)
CAT II 600 V (with flat test bar)
1 A mark for securing the minimum required creep and spatial
distance to prevent electric shock during operation.
