35
IM MY600-01EN
Line Probe with Remote Switch (98008)
The following probe tips are available.
Standard probe tip Comes attached to the probe with a
detachable insulation cap.
Probe tip 99013 (long type)
Used in situations where the standard
probe tip is not long enough.
99013
Hexagon hole
Female thread
Male screw
Probe tip
Standard probe tip
Tip cover
How to Replace
Turn the probe tip counterclockwise, and remove it.
Insert the probe tip you want to use into the hexagonal hole
in the tip cover, and turn it clockwise to tighten firmly.
Earth Probe Set (98009)
Attach an alligator clip or flat test bar to the earth probe.
How to Attach
Insert the alligator clip or flat test bar firmly into the tip of
the cable with banana plugs on both ends.
Alligator clip
Flat test bar
Cable with banana plugs
on both ends
To Next Page
