IM 12B6C3-E-E
Parameter setting 5-14
Code Display Function Function detai• X Y Z Default values
Temperature measuring and compensation functions
10 *T.SENS Temperature sensor Pt1000 0 0 Pt1000
Pt100 1
3kBalco 2
5k1 3
8k55 4
350 5
6k8 6
PTC10k 7
11 *T.UNIT Display in °C or °F °C 0 0 °C
°F 1
12 *T.ADJ Calibrate temperature Adjust to allow for cable resistance None
13 *T.COMP Set temp comp Compensation for process changes off 0 0 Off
Compensation for process changes on 1
*T.COEF Adjust process TC Set for TC in pH per 10 °C -0.00 pH per
10 °C
14-19 Not used
