IM 12B6C3-E-E
9-1 Spareparts
9. SPARE PARTS
Table 9-1. Itemized parts list
Item No. Description Part no.
1 Cover assembly including window, gasket and fixing screws K1542JZ
2 Window K1542JN
3a Internal works assembly (general purpose) K1544DA
3b Internal works assembly (intrinsically safe) K1544DD
4 Digital (display) board K1544DH
5a Analog (input) board (general purpose) K1544PL
5b Analog (input) board (intrinsically safe) K1544PE
6 Ribbon cable K1544PH
7 Eeprom + latest software pH202 K1544BK
8 Lithium cell (battery) K1543AJ
9 Terminals (block of 3) K1544PF
10 Terminals (block of 5) K1544PG
11 Housing K1542JL
12 Gland set (one gland including seal and backing nut) K1500AU
13 HART
®
modem for communications to PC K1544WM
Options
/U Pipe and wall mounting hardware K1542KW
/H Hood for sun protection K1542KG
/SCT Stainless steel tag plate K1544ST
