YOKOGAWA PH202G (S) - 10 Appendix; User Setting Table

IM 12B6C3-E-E
Appendix 10-1
10. APPENDIX
10-1. User setting table
FUNCTION SETTING DEFAULTS USER SETTINGS
Parameter specific functions
01 *PH.ORP 0 pH
02 *PRM2 0 Off
03 *Z1.CHK 1.1.1 High range, TC on
check on,
04 *Z2.CHK 0.0.1 Low range, TC off
check off no TC
05 *CAL.CK 1.1 AP on, Slope on
Temperature functions
10 *T.SENS 0 Pt1000
11 *T.UNIT 0 °C
12 *T.ADJ None
13 *T.COMP 0 Off
*T.COEF -0.00 pH/10°C
Calibration functions
20 *t.SEC 5 Sec
*pH 0.02 pH
21 *AP.LOW -120 mV
*AP.HI 120 mV
22 *SL.LOW 70 %
*SL.HI 110 %
23 *ITP 7.00 pH
*SLOPE 100.0 %
*ASP.1D 0.0 mV
*ASP.mV mV
24 *BUF.ID 4 NIST 4
25 *BUF.ID 7 NIST 7
26 *BUF.ID 9 NIST 9
27 *ZERO.P 0 disabled
mA outputs
31 *OUTP.F 0 pH (ORP)
32 *BURN 0 off
35 *TABLE 21 pt table see code 31
mA
mA
mA
