Mode• Suffix Code Option code Description
PH202G PH/ORP Transmitter, General Purpose version
Type - E Milli-amp (+HART) version, European style
- C Milli-amp (+HART) version, Canadian style
- U Milli-amp (+HART) version, North American style
- F FOUNDATION ® Fieldbus version
- P Profibus PA version
- E Always E
Options /H Hood for Sun Protection
/U Pipe & Wall mounting hardware
/SCT Stainless steel tagplate
/Q Calibration certificate
Mode• Suffix Code Option code Description
PH202S PH/ORP Transmitter, Intrinsic Safe version
Type - E Milli-amp (+HART) version, European style
- C Milli-amp (+HART) version, Canadian style
- U Milli-amp (+HART) version, North American style
- F FOUNDATION ® Fieldbus version
- P Profibus PA version
- N Non-Incendive Milli-amp (+HART) version
- B Non-Incendive FOUNDATION ® Fieldbus version
- D Non-Incendive Profibus PA version
- E Always E
Options /H Hood for Sun Protection
/U Pipe & Wall mounting hardware
/SCT Stainless steel tagplate
/Q Calibration certificate
2-3. Model and suffix codes
N. Regulatory compliance
- EMC : meets council directive 89/336/EEC
- Emmission : meets EN 55022 Class A
- Immunity : meets EN 61000-6-2
O. Intrinsic safety
- ATEX
: EEx ib [ia] IIC T4 for Ta -10 to 55 ºC
EEx ib [ia] IIC T6 for Ta -10 to 40 ºC
II 2 (1) G KEMA 00ATEX1068 X
- CSA : Ex ia CL 1, DIV 1, GP C&D,
T3C for Ta -10 to 55 ºC
Refer to Installation Drawing
PH202S CSA
- FM : IS CL 1, DIV 1, GP ABCD
T3B for Ta -10 to 55 ºC
T4 for Ta -10 to 40 ºC
HAZ LOC per Control Drawing
FF1-PH202S-00
P. Non-Incendive
- FM : NI CL 1, DIV 2, GP ABCD
T3B for Ta -10 to 55 ºC
T4 for Ta -10 to 40 ºC
HAZ LOC per Control Drawing
FF1-PH202S-00
- ATEX : EEx nA [L] IIC T4 for Ta -10 to 55 ºC
EEx nA [L] IIC T6 for Ta -10 to 40 ºC
II 3 G KEMA 00ATEX1115 X
