IM 12B6C3-E-E
Parameter setting 5-22
Code Display Function Function detai• X Y Z Default values
Communication
60 *COMM. Communication Set communication Off 0 1.0 On
Set communication On 1
write enable 0 write
write protect 1 enable
Set communication PH201
*
B 2
Without half time check 0
With half time check 1
*ADDR. Network address Set address 00 to 15 00
61 *HOUR Clock setup Adjust to current date and time using
*MINUT >, ^ and ENT keys
*SECND
*YEAR
*MONTH
*DAY
62 *ERASE Erase logbook Press YES to clear logbook data
63-69 Not used
Code Display Function Function detai• X Y Z Default values
General
70 *LOAD Load defaults Reset configuration to default values
71-78 Not used
79 *CUST.D Load Customer Reset configuration to default values
Defaults except buffer tables
Code Display Function Function detai• X Y Z Default values
Test and setup mode
80 *TEST Test and setup Built in test functions as detailed in QIS
and Service Manual
mA
mA
