IM 12B07D02-01E
Appendix 11-9
11-4-4. Setting of errors (FAIL contact)
Code 53 *Err.4.1-*Err .16 (9 items)
These set how errors are notified to the user. Either of two modes can be set. "Hard
Fail" mode lights the "FAIL" indicator on the LCD panel. When "enable status output
contact" is set for the PH201G distributor (Style B), the FAIL contact remains closed and
the "wash" contact stops operating. If Burnout functions are enabled by Code 32, then
the output becomes Burnout Upscale or Burnout Downscale.
"Soft Fail" mode blinks the "FAIL" indicator on the LCD panel. When "enable status
output contact" is set for the PH201G distributor (Style B), the FAIL contact pulses and
the "wash" contact and maintenance contact continue to operate normally. In "Soft Fail"
mode, notification that "periodic maintenance is due" still functions (service code 55) so
– for this reason – it is better to set "Soft Fail" mode than "Hard Fail" mode.
T5.3.5E.eps
Code Display Function Function detail X Y Z Ddefault values
User interface
53 *Err.4.1 Error setting Impedance low (input 1) Soft fail 0
Impedance low (input 1) Hard fail 1 1 Hard
*Err.5.1 Impedance higt (input 1) Soft fail 0
Impedance high (input 1) Hard fail 1 1 Hard
*Err.4.2 Impedance low (input 2) Soft fail 0
Impedance low (input 2) Hard fail 1 1 Hard
*Err.5.2 Impedance higt (input 2) Soft fail 0
Impedance high (input 2) Hard fail 1 1 Hard
*Err.07 Temperrature too high Soft fail 0
Temperrature too high Hard fail 1 1 Hard
*Err.08 Temperrature too low Soft fail 0
Temperrature too low Hard fail 1 1 Hard
*Err.09 pH out of range Soft fail 0
pH out of range Hard fail 1 1 Hard
*Err.11 Wash recovery check Soft fail 0 0 Soft
Wash recovery check Hard fail 1
*Err.16 Call for maintenance Soft fail 0 0 Soft
Call for maintenance Hard fail 1
To Next Page
