IM12B07D02-01E
5-18 Parameter setting
Code Display Function Function detail X Y Z Default values
mA Outputs
30 Not used
31 *OUTP.F mA output functions pH 0 0
Code 01 set for pH pH (table) 1
Parameter 2 (with suitable sensor(s), 2
and when enabled in code 02)
32 *BURN Burn function No burnout 0 0 No Burn.
Burnout downscale 1
Burnout upscale 2
Pulse burnout 3
33, 34 Not used
35 *TABLE Output table for mA
*0% Linearisation table for mA1 in 5% steps.
*5% The measured value is set in the main
*10% display using the >, ^, ENT keys, for
... each of the 5% interval steps.
...
Where a value is not known, that value may
*90% be skipped, and a linear interpolation will
*100% take place.
36-39 Not used
mA
