l
Power Cable W
iring
Connect the power cables according to the procedure specified in the User’s Manuals of the
device.
Power cables must conform to the safety standards of the country where the device is instal-
led.
SEE
ALSO
For more information about power cables wiring, refer to:
• 3.1, “Power Cable Wiring” on page 3-2
• ProSafe-RS Installation Guidance (TI 32S01J10-01E)
• User's Manuals of each device
l
Grounding
The Product requires the protective grounding defined by the safety standards.
Y
ou must ground the Product according to the procedure specified in the User's Manuals to
prevent electric shock and to minimize the effect of noise.
SEE
ALSO
For more information about grounding, refer to:
• 3.2, “Grounding” on page 3-6
• ProSafe-RS Installation Guidance (TI 32S01J10-01E)
• User's Manuals of each device
l
I/O Cable W
iring
Wire I/O cables according to the procedure specified in the User’s Manuals.
SEE
ALSO
For more information about I/O cable wiring, refer to:
• 5., “Signal Cable Connection to Input/Output Modules” on page 5-1
• ProSafe-RS Installation Guidance (TI 32S01J10-01E)
• User's manual of each device
ix
IM 32Q06C10-31E 4th Edition : Jan.30,2015-00
