• Setting DIP switches
0: The switch is flipped down in the following diagram.
1: The switch is flipped up in the following diagram.
Bit 2 of the DIP switch is always 0.
LSB
MSB
1
0
MSB : Most Significant Bit (highest-order bit)
LSB : Least Significant Bit (lowest-order bit)
P 0
Domain number (6 bits) (An example where the address “Domain Number” 6)
Fixed to 0
Domain number parity (1 bit, odd parity)
2 1 3 4 5 6 7 8
Bit number
Figure 6.7-3 DIP Switches for Domain Number Setting
Table 6.7-1 Domain Numbers and Switch Positions
Domain number
DIP switch bit number
1 2 3 4 5 6 7 8
1 0 0 0 0 0 0 0 1
2 0 0 0 0 0 0 1 0
3 1 0 0 0 0 0 1 1
4 0 0 0 0 0 1 0 0
5 1 0 0 0 0 1 0 1
6 1 0 0 0 0 1 1 0
7 0 0 0 0 0 1 1 1
8 0 0 0 0 1 0 0 0
9 1 0 0 0 1 0 0 1
10 1 0 0 0 1 0 1 0
11 0 0 0 0 1 0 1 1
12 1 0 0 0 1 1 0 0
13 0 0 0 0 1 1 0 1
14 0 0 0 0 1 1 1 0
15 1 0 0 0 1 1 1 1
16 0 0 0 1 0 0 0 0
17 1 0 0 1 0 0 0 1
18 1 0 0 1 0 0 1 0
19 0 0 0 1 0 0 1 1
20 1 0 0 1 0 1 0 0
21 0 0 0 1 0 1 0 1
22 0 0 0 1 0 1 1 0
23 1 0 0 1 0 1 1 1
24 1 0 0 1 1 0 0 0
25 0 0 0 1 1 0 0 1
26 0 0 0 1 1 0 1 0
27 1 0 0 1 1 0 1 1
Continues on the next page
<6.7 Setting the Vnet/IP Interface Card Station Address > 6-13
IM 32Q06C10-31E 4th Edition : Jan.30,2015-00
