Table 6.7-1 Domain Numbers and Switch Positions (T
able continued)
Domain number
DIP switch bit number
1 2 3 4 5 6 7 8
28 0 0 0 1 1 1 0 0
29 1 0 0 1 1 1 0 1
30 1 0 0 1 1 1 1 0
31 0 0 0 1 1 1 1 1
l
Setting the Station Number
Set the station number in the range of 1 to 64. T
o set a station number, set the DIP switches
as shown in the following table.
• Setting DIP switches
0: The switch is flipped down in the following diagram.
1: The switch is flipped up in the following diagram.
1
0
2
1
3
4
5
6
7
8
P
LSB
Station number (7 bits) (An example where the address “Station Number” 60)
MSB : Most Significant Bit (highest-order bit)
LSB : Least Significant Bit (lowest-order bit)
Station number parity (1 bit, odd parity)
Bit number
MSB
Figure 6.7-4 DIP Switches for Setting Station Numbers
Table 6.7-2 Station Number and DIP Switch Positions
Station number
DIP switch bit number
1 2 3 4 5 6 7 8
1 0 0 0 0 0 0 0 1
2 0 0 0 0 0 0 1 0
3 1 0 0 0 0 0 1 1
4 0 0 0 0 0 1 0 0
5 1 0 0 0 0 1 0 1
6 1 0 0 0 0 1 1 0
7 0 0 0 0 0 1 1 1
8 0 0 0 0 1 0 0 0
9 1 0 0 0 1 0 0 1
10 1 0 0 0 1 0 1 0
11 0 0 0 0 1 0 1 1
12 1 0 0 0 1 1 0 0
13 0 0 0 0 1 1 0 1
14 0 0 0 0 1 1 1 0
15 1 0 0 0 1 1 1 1
16 0 0 0 1 0 0 0 0
17 1 0 0 1 0 0 0 1
18 1 0 0 1 0 0 1 0
Continues on the next page
<6.7 Setting the Vnet/IP Interface Card Station Address > 6-14
IM 32Q06C10-31E 4th Edition : Jan.30,2015-00
