Table 6.7-2 Station Number and DIP Switch Positions (T
able continued)
Station number
DIP switch bit number
1 2 3 4 5 6 7 8
.
.
.
.
.
.
30 1 0 0 1 1 1 1 0
31 0 0 0 1 1 1 1 1
32 0 0 1 0 0 0 0 0
33 1 0 1 0 0 0 0 1
.
.
.
.
.
.
60 1 0 1 1 1 1 0 0
61 0 0 1 1 1 1 0 1
62 0 0 1 1 1 1 1 0
63 1 0 1 1 1 1 1 1
64 0 1 0 0 0 0 0 0
n
Action Mode Switch
SW4 on the printed circuit board is the action mode switch.
Use the card with all the bits of this DIP switch set to OFF (factory set defaults). The meaning
of DIP switch bits are as follows:
O
F
F
2 1 3 4
A B C D
Bit number
Figure 6.7-5 Action Mode Switch
Table 6.7-3 DIP Switch Usage
DIP switch ON DIP switch OFF Remarks
A (bit 1) - Always OFF Reserved
B (bit 2) 100 Mbps 1 Gbps Communication speed (Default : OFF)
C (bit 3) Force Auto Negotiation (Default : OFF)
D (bit 4) - Always OFF Reserved
<6.7 Setting the Vnet/IP Interface Card Station Address > 6-15
IM 32Q06C10-31E 4th Edition : Jan.30,2015-00
