• Replace a battery pack when the validity period expires.
•
Order a new battery at least one month before the validity period expires.
• Wear a wrist strap when handling a battery pack.
• Do not short-circuit the battery terminals.
• Do not heat the battery or throw a battery pack in a fire. The problems of leaking, over-
heating or breaking may occur.
• Do not disassemble or modify the battery pack.
• Do not use this type of battery pack to the products other than Yokogawa designated de-
vices.
• When discarding the battery packs, they should be handled very carefully to avoid pollut-
ing environment.
l
Procedure for Removing Battery
1.
Open the front cover of the processor module.
2. Turn the battery ON/OFF switch to OFF position.
A stick of insulation material should be used to toggle the battery switch.
3. Disconnect the battery cable from the connector (displayed as CN2).
The battery cable connector has a self-locking elastic clip. When pulling out the connec-
tor, it is necessary to push the clip to unlock it.
4. Pull out the battery starlight.
TIP
This is an explanation about the new EU Battery Directive(DIRECTIVE 2006/66/EC).This directive is only val-
id in the EU.
The batteries are used in the processor modules. When you remove batteries from the processor modules,
you should dispose the batteries in accordance with the domestic law concerning waste battery disposal.
Take a right action on waste batteries, because the collection system in the EU on waste batteries are regula-
ted.
Battery type: Lithium Thionyl Chloride Batteries
Figure 7.7.1-2 The Symbol Marked on Battery
The symbol marked on the battery means the battery must be separately collected as regulated by ANNEX II
in DIRECTIVE 2006/66/EC.
l
Procedure for Installing Battery
1.
Place the battery to the specified position on the processor module.
The following figure shows the SCP451/SCP401 battery. When using the SCP461, store
in a vertical position.
<7.7 Parts Requiring Periodical Replacement > 7-35
IM 32Q06C10-31E 4th Edition : Jan.30,2015-00
To Next Page
