Table 8.3.1-4 Connector Numbers and Connected Field Terminal Numbers (T
able continued)
Connector num-
ber
Connection Field terminal number Remarks
CN3
SDV144
TM1 (1-8),
TM2 (9-16)
Readback; CN3/CN4 redundancy
CN4
The following table shows the relations among the relay numbers, the field terminals, the digi-
tal output module connectors, and the SDV541/SDV144 channel numbers.
Table 8.3.1-5 Relay Numbers/ Field Terminals/ Channel Numbers
Relay num-
ber (*1
)
Field terminal
CN1 CN2 CN3 CN4
SDV541/SDV144 Channel number
SDV541 SDV144
1 TM1 1A/1B ch1 ch1 ch1 ch1
2 TM1 2A/2B ch2 ch2 ch2 ch2
3 TM1 3A/3B ch3 ch3 ch3 ch3
4 TM1 4A/4B ch4 ch4 ch4 ch4
5 TM1 5A/5B ch5 ch5 ch5 ch5
6 TM1 6A/6B ch6 ch6 ch6 ch6
7 TM1 7A/7B ch7 ch7 ch7 ch7
8 TM1 8A/8B ch8 ch8 ch8 ch8
9 TM2 9A/9B ch9 ch9 ch9 ch9
10 TM2 10A/10B ch10 ch10 ch10 ch10
11 TM2 11A/11B ch11 ch11 ch11 ch11
12 TM2 12A/12B ch12 ch12 ch12 ch12
13 TM2 13A/13B ch13 ch13 ch13 ch13
14 TM2 14A/14B ch14 ch14 ch14 ch14
15 TM2 15A/15B ch15 ch15 ch15 ch15
16 TM2 16A/16B ch16 ch16 ch16 ch16
*1: The relay number is the number printed on the SRM54D metal body above each relay.
The output status, the LED status and the SDV144 readback status are shown in the follow-
ing table.
Table 8.3.1-6 Output Status, LED status, and SDV144 Readback Status
SDV541 Output status
(*1)
LED status Field terminal status
SDV144 readback sta-
tus(*1)
OFF OFF(*2) OFF (Open) ON (Close)
ON ON ON (Close) OFF (Open)
*1: The output contacts are A type (NO: Normally Open), and SDV144 status contacts are B type (NC: Normally Close).
*2: If the ON pulse diagnosis for SDV541 is enabled and the SDV541 output status is set to OFF, the LED goes ON for each ON
pulse output.
When SDV144 is connected to SRM54D, Detect Disconnection and Detect Short Circuit
should be disabled on I/O Parameter Builder
.
<8.3 Cable Connection > 8-8
IM 32Q06C10-31E 4th Edition : Jan.30,2015-00
