A part
B part
DIN rail
Figure 8.5.1-7 Uninstalling from a DIN Rail
l
Fasteners
When installing a relay board onto a DIN rail, you can use fasteners to hold it in place. These
fasteners are not supplied and should be purchased separately. Mount the relay board on the
DIN rail first and then secure it in place with the fasteners. To remove the board, take the fas-
teners off and then remove the relay board from the DIN rail.
<8.5 Maintenance > 8-22
IM 32Q06C10-31E 4th Edition : Jan.30,2015-00
