able 4.2.3-5 Station Number and DIP Switch Positions
Station number
17
18
- - - - -
30
31
32
33
- - - - - - - -
60
61
62
63
64
Bit 1
1
1
- - - - -
1
0
0
1
- - - - - - - -
1
0
0
1
0
Bit 2
0
0
0
0
0
0
0
0
0
0
1
Bit 3
0
0
0
0
1
1
1
1
1
1
0
Bit 4
1
1
1
1
0
0
1
1
1
1
0
Bit 5
0
0
1
1
0
0
1
1
1
1
0
Bit 6
0
0
1
1
0
0
1
1
1
1
0
Bit 7
0
1
1
1
0
0
0
0
1
1
0
Bit 8
1
0
0
1
0
1
0
1
0
1
0
<4.2 Processor Module >
4-12
IM 32Q06C10-31E
4th Edition : Jan.30,2015-00
98
100
Table of Contents
Table of Contents
17
Hardware Configuration and Names of Components
21
Configuration of Safety Control Unit
23
Configuration of Safety Node Unit
30
Configuration of Unit for Optical Bus Repeater Module
31
Input/Output Modules
32
Analog Input/Output Modules
33
Digital Input/Output Modules
36
Communication Modules
38
Accessories Related to Input/Output Modules
39
Pressure Clamp Terminal Blocks
40
Connector Cover for MIL Cable
41
Terminal Boards
42
Relay Boards
46
Wiring Check Adapter for Digital Input
48
Installing Devices
50
Installing Rack Mountable Devices
51
Installing a Terminal Board
54
Installing a 19-Inch Rack Mountable Terminal Board
55
Installing a DIN Rail Mountable Terminal Board
56
Precautions During Installation
59
Cable Connection
60
Power Cable Wiring
61
Grounding
65
Connecting Control Bus Cables
67
Connecting V Net Cable
68
Connecting Cables for Vnet/Ip
76
Connecting ESB Bus Cable
78
Connecting ESB Bus Cable
81
Connecting ESB Bus Fiber-Optic Cable
81
Configuration and Functions of each Unit
88
Power Supply Module
89
Processor Module
90
Battery
92
LED Display
93
Setting Switches
95
ESB Bus Coupler Module
100
ESB Bus Interface Module
102
<4.5 Optical ESB Bus Repeater Module
106
Net Coupler Unit
107
External Interface Unit
108
Node Fan Unit
110
Power Distribution Unit
112
Signal Cable Connection to Input/Output Modules
115
Configuration of Input/Output Module Connections
116
How to Connect Signal Cables
118
Direct Connection Using Pressure Clamp Terminals
119
Connecting an Input/Output Module to a Terminal Board
122
Connecting a Terminal Board to the Field
124
Connection Via MIL Connectors
127
Signal Cable Connection to Analog Input/Output Modules
128
Analog Input Module, 16-Channel (SAI143)
130
Analog Input Module, 16-Channel (SAV144)
131
Analog Output Module, 8-Channel (SAI533)
132
Connection with a Terminal Board (Analog Input/Output Module)
133
Signal Cable Connection to Digital Input/Output Modules
136
Digital Input Module, 16-Channel (SDV144)
139
Digital Output Module, 8-Channel (SDV531)
140
Digital Output Module, 16-Channel (SDV541)
141
Connection with a Terminal Board (Digital Input/Output Module)
142
Connection of Communication Modules
148
Connection of RS-232C Communication Module
149
Connection of RS-422/RS-485 Communication Module
155
Connection of Ethernet Communication Module
160
Circuit Diagrams of Input/Output Modules
161
Control Bus Interface Card
169
Front Panel of the Control Bus Interface Card
170
Setting Control Bus Interface Card Station Address
171
Installing the Control Bus Interface Card to a PC
175
Connecting V Net Cables to the Control Bus Interface Card
176
Attaching the V Net Station Address Label
178
Front Panel of the Vnet/Ip Interface Card
179
Setting the Vnet/Ip Interface Card Station Address
180
Installing the Vnet/Ip Interface Card in a PC
184
Attaching the Vnet/Ip Station Address Label
186
Maintenance of Prosafe-RS Hardware
187
Routine Maintenance of Safety Control Unit
188
Inspection by Status Display Leds
189
Inspection by SCS State Management Window
191
Replacing Common Modules
192
Replacing V Net Coupler Unit
193
Replacing Power Supply Module
194
Replacing Processor Module
196
Replacing ESB Bus Coupler Module
200
Replacing ESB Bus Interface Module
201
Replacing Optical ESB Bus Repeater Module
202
Exchange ESB Bus Cables
204
Exchange Fiber-Optic Cables
205
Replacing Input/Output Modules
206
Notices on Maintenance of Input/Output Modules
207
How to Replace Input/Output Modules
209
How to Change Fuse of Contact Digital Input Module (SDV144 Style S1, S2, and S3)
212
Replacing Safety Node Unit
213
Adding Safety Node Unit
214
Removing Safety Node Unit
216
Parts Requiring Periodical Replacement
218
Replacing Battery
220
Replacing Node Fan Unit
223
Replacing Parts on Terminal Board
226
Relay Board
228
Handling Relay Board
229
Names of Parts
230
Cable Connection
231
Connecting to Digital I/O Modules
232
Contact Output Wiring and Ground Wiring
237
Wiring Field Equipment
238
Circuit Diagram
242
Maintenance
245
Mounting Relay Boards
246
Parts Replacement
250
Cmpl 32S06C10-01E (Ssc10, Ssc50)
251
Cmpl 32S06K10-01E (Snb10D)
255
Cmpl 32S06K11-01E (Snt10D)
257
