<Toc> <2. Initial Settings>
2-1
IM 05D01D02-41E
2. Initial Settings
This chapter describes examples of setting PV input types, control output types, and
alarm types. Carrying out settings described herein allows you to perform basic
control. Refer to examples of various settings to understand how to set parameters
required. Refer to “5.1 Parameter Map” for an easy to understand explanation of
setting various parameters. If you cannot remember how to carry out an operation
during setting, press the
SET/ENT
key for more than 3 seconds. This brings you to the
display (operating display) that appears at power-on.
Power-on
Set the alarm
type and other setup
parameters.
See “2.2 Setting PV Input Type (Setting First at Power-on),”
or “2.3 Changing PV Input Type.”
Set the control
output.
(Factory-set to “Time Proportional Relay Output.”)
Denotes a step that must always be followed.
(Factory-set to “Unspecified.”)
Denotes a step that should be followed as necessary.
Setup Procedure
Set operating
parameters.
Controller operation
See “2.4 Setting Control Output Type.”
Set PV input.
The following explanation of operation for the UT350’s panel, shown in the figure, is the
same as that of the UT320’s panel.
1st Edition : May 31,2000-00
To Next Page
