i
<Int> <T
oc>
IM 05D01D02-41E
Revision Information
●
Title
:
Models UT350/UT320 Digital Indicating Controllers User’s Manual
●
Manual No.
:
IM 05D01D02-41E
May 2000/1st Edition
Newly published
Written by
Products Documents
Controllers & Conditioners Division
Yokogawa M&C Corporation
Published by
Yokogawa M&C Corporation
1-19-18 Nakacho, Musashino-shi, Tokyo 180-0006, JAPAN
1st Edition : May 31,2000-00
80
82
Table of Contents
Default Chapter
5
Table of Contents
5
1 Installation
7
Model and Suffix Codes
7
How to Install
8
How to Connect Wires
11
Hardware Specifications
13
Terminal Wiring Diagrams
18
2 Initial Settings
23
Names and Functions of Front Panel Parts
24
Setting PV Input Type (Setting First at Power-On)
25
Changing PV Input Type
28
Setting Control Output Type
30
Changing Alarm Type
31
Description of Multiple Setpoints and PID
34
3 Operations
35
Monitoring-Purpose Operating Displays Available During Operation
35
Setting Target Setpoint (SP)
37
Performing/Canceling Auto-Tuning
38
Setting PID Manually
39
Setting Alarm Setpoints
40
Selecting Target Setpoint Numbers (SP.NO)
41
Switching between Run and Stop
42
Switching between AUTO and man
43
Manipulating Control Output in Manual Operation
44
4 Troubleshooting and Maintenance
47
Troubleshooting
47
Maintenance
50
Cleaning
50
Replacing Brackets
50
Attaching Terminal Cover
50
Replacing Parts with a Limited Service Life
52
Replacing Control Output Relays
53
5 Parameters
57
Parameter Map
57
Lists of Parameters
60
6 Function Block Diagram and Descriptions
73
Other manuals for YOKOGAWA UT320
User Manual
90 pages
4
Based on 1 rating
