1.
Bring the operating display into view (display appears at power on).
AL
A/M
PV
REM1
CAS
REM2
MAN1
MAN2
STP
2
4
1
3
PV2
AL
DISP
SET/ENT
SP :1.
-10 0 +10
100.0°C
DV
REM1 lamp
OFF.
Displays PV.
Displays
target setpoint-1
“1.SP”.
In steps 2 and later, illustrations of the LCD are cited to explain the procedure.
2.
Press the
SET/ENT
key for more than 3 seconds
to call up the main menu “MODE”.
mode parameter
main menu
MODE
A/M
DISP
SET/ENT
3.
Press the
SET/ENT
key several times to display
the parameter “MODE:LOCAL”.
A/M
DISP
SET/ENT
MENU:MODE #3
REM/LOC1 select
MODE : LOCAL
4.
Press the or key to display “RE-
MOTE”.
MENU:MODE #3
changing
REM/LOC1 select
MODE : REMOTE
A/M
DISP
SET/ENT
Blinks during
change.
5.
Press the
SET/ENT
key once to register the
setpoint.
A/M
DISP
SET/ENT
MENU:MODE #3
REM/LOC1 select
MODE : REMOTE
Automatically return to the display shown at power-on (figure below).
AL
A/M
PV
REM1
CAS
REM2
MAN1
MAN2
STP
2
4
1
3
PV2
AL
DISP
SET/ENT
SP : R.
-10 0 +10
120.0°C
DV
REM1 lamp
ON.
Displays
a remote
input symbol
“R.SP”.
