5-6
<Toc> <5. Parameters>
IM 05D01B02-41E
5.2 Lists of Parameters
This section describes the functions of parameters briefly. In addition, each parameter table
has a “User Setting” column, where you can record your setpoints when setting them in the
controller.
* Parameters relating to PV or setpoints should all be set in real numbers.
For example, use temperature values to define target setpoints and alarm setpoints
for temperature input.
* The “User Setting” column in the table is provided for the customer to record setpoints.
* The column “Target Item in CD-ROM” in the table provides references from User’s
Manual (Reference) (CD-ROM version) which describes items in more detail and
items that are not contained in this manual.
* Numbers in ( ) are the parameter setpoints that apply when the communication func-
tion is used. ex. REMOTE (1), LOCAL (0).
■ Operating Parameters
● Operation Mode Parameters
Located in: Main menu = MODE



Parameter
Symbol
Name of Parameter Setting Range and Description Initial Value User
Setting
Target Item
in CD-ROM
Remote/Local
switching
Set to “Local” when carrying out control using the target setpoints of
the controller or to “Remote” when using target setpoints acquired via
a remote input signal or communication.
Use the setup parameter RMS, “Remote Input Selection,” to
determine whether the target setpoints should be acquired via the
remote input signal or communication.
REMOTE (1): Remote mode
LOCAL (0): Local mode
LOCAL (0)
1
Run/Stop switching Outputs the predetermined (preset) fixed value when the controller
stops. A preset output value can be defined for each target setpoint
using the operating parameter “PO”.
STOP (1): Stops operation.
RUN (0): Starts operation.
RUN (0)
Target setpoint
number selection
1: Selects target setpoint-1 (1.SP). 2: Selects target setpoint-2 (2.SP).
3: Selects target setpoint-3 (3.SP). 4: Selects target setpoint-4 (4.SP).
Likewise, options 5 to 8 select target setpoints 5 (5.SP) to 8 (8.SP).
MODE
(R/L1)
MODE
(S/R)
SPNO
1st Edition : May 31,2000-00
