1. Installation

This chapter describes installation, wiring, and other tasks required to make the

controller ready for operation.

1.1 Model and Suffix Codes

Before using the controller, check that the model and suffix codes match your order.

Model Suffix Code Description

UT750 Digital indicating controller (provided with Custom Computing Function*)

-0 Single-loop type

-1 Position proportional type

-5 Dual-loop type

Type

0 None

1 With communication, remote input

Optional functions

Check that the following items are provided:

• Digital indicating controller (of ordered model) ........................................ 1

• Brackets (mounting hardware) ............................................................... 1 pair

• Unit label................................................................................................ 1

• User’s Manuals for Single-loop Control .................................................. 5 (A2 size)

• User’s Manual (Reference) (CD-ROM version) ...................................... 1

* Using an optional custom computation building tool (Model LL200-E10) that runs on a personal computer, you can

build a variety of computations (e.g., four arithmetic operations, logical operations, ten-segment linearizer computa-

tions, temperature correction factor computations, and pressure correction factor computations) to be applied to the

controller’s I/O signals.
