<Toc> <1. Installation>
1-3
IM 05D01B02-41E
■ External Dimensions and Panel Cutout Dimensions
PV
PV2
AL
CAS
REM1
REM2
MAN1
MAN2
STP
3
4
2
1
DISP
SET/ENT
A/M
(25)
(53)
[(N-1)96+92]117 min.
145 min.
+0.8
0
+0.8
0
92
+0.8
0
92
+0.8
0
92
“N” stands for the number of controllers to be
installed.
However, the measured value applies if N 5.
10011
UT750
1 to 10 mm (Panel thickness)
Small bracket
Large bracket
91.8
112
Unit: mm
96
96
General installation Side-by-side close installation
1st Edition : May 31,2000-00
To Next Page
