YOKOGAWA WT5000 Features Guide

1-2
IM WT5000-01EN
Frequency
Function Description Input Element Wiring Unit
fU Voltage frequency Yes No
fI Current frequency Yes No
f2U Voltage frequency Yes No
f2I Current frequency Yes No
fPLL1 Frequency of PLL1 No No
fPLL2 Frequency of PLL2 No No
Integrated Power (Watt hours)
Function Description Input Element Wiring Unit
ITime Integration time Yes No
WP Sum of positive and negative watt
hours
Yes Yes
WP+ Sum of positive P values Yes Yes
WP− Sum of negative P values Ye s Ye s
q Sum of positive and negative ampere
hours
Yes Yes
q+ Sum of positive I values Yes Yes
q− Sum of negative I values Yes Ye s
WS Volt-ampere hours Yes Yes
WQ Var hours Yes Yes
Efficiency
Function Description
η1 to η4 Efficiency
User-Defined Functions
Function Description
F1 to F20 User-defined functions
User-Defined Events
Function Description
Ev1 to Ev8 User-defined events
1 Items That This Instrument Can Measure

YOKOGAWA WT5000 Specifications

General

Frequency Range	DC, 0.1 Hz to 1 MHz
Number of Channels	Up to 7
Interfaces	USB, Ethernet, GP-IB, RS232
Sampling Rate	10 MS/s
Harmonic Analysis	Up to the 500th order
Weight	Approximately 15 kg
Display	10.1-inch WXGA (1280 x 800) TFT LCD
