YOKOGAWA WT5000 Features Guide

5-6
IM WT5000-01EN
Input Signal Type (Sense Type)
Select the input signal from the following two types.
• Analog (Analog): Select this option when this instrument will receive DC voltage (analog) signals.
• Pulse (Pulse): Select this option when this instrument will receive pulse signals.
Settings for Different Input Signal Types
As indicated below, the settings that you need to configure vary depending on the input signal type.
Settings Related to the Signal Type
Setting Signal Type
Analog Pulse
Analog auto range Yes No
Analog range Yes No
Linear scale A, B Yes No
Line filter Yes No
Pulse noise filter No Yes
Sync source*
— —
Pulse range No Yes
Number of pulses per revolution* No Ye s
Yes: Must be set.
No: Does not need to be set.
—: Measurement can be performed when the sync source is set to None (the default setting), but you can
increase synchronicity with power measurement by specifying a sync source.
Common Settings Unrelated to the Signal Type
• Scaling factor
• Unit
• Motor poles*
• Sync speed frequency measurement source*
* When the MTR configuration is set to auxiliary input (Aux), do not set this item.
5 Motor Evaluation and Auxiliary Input (Option)
