16-9
IM WT5000-01EN
Starting, Pausing, and Ending Storage Recording
Starting Storage Recording (Rec, REC)
• When you tap Rec or press REC, storage starts under one of the conditions described below, depending on
the storage mode.
• Manual (Manual)
Storage starts immediately.
• Real-Time Control (Real Time)
This instrument enters into a storage-ready state. Storage starts when the scheduled storage start time is
reached.
• Integration Synchronization (Integ Sync)
This instrument enters into a storage-ready state. Storage starts when integration starts.
• Event Synchronization (Event)
This instrument enters into a storage-ready state. Storage starts when a user-defined event occurs.
• Single Shot (Single Shot)
Storage starts immediately. Numeric data is stored whenever you tap Rec or press REC.
• When storage starts, the REC key illuminates, and “REC” appears at the top of the screen.
• When this instrument is in a storage-ready state, the REC key blinks, and “READY” appears at the top of the
screen.
• After storage is reset, a storage data file (.wts) and header file (.hds) are created when storage starts again.
• When the storage is paused (PAUSE), you can restart storage. When you restart storage, the stored data
continues to be written to the file from before storage was paused.
• When the storage has been completed (CMPL), you cannot restart storage until you end the storage (END).
After you end storage and then start it, a new storage data file is created and written to.
Pausing Storage (Pause, PAUSE)
• Tap Pause or press PAUSE to pause the storage operation.
• When storage is paused, the PAUSE key blinks, and “PAUSE” appears at the top of the screen.
• When the storage count is zero and this instrument is in a storage-ready state (READY) and you tap Pause or
press PAUSE, storage ends.* The storage data file (.wts) and storage header file (.hds) are deleted.
* This state can occur in real-time storage mode when you have tapped Rec or pressed REC but the
scheduled storage start time has not yet arrived (the storage operation has not begun).
16 Data Storage
To Next Page
