External Current Sensor On/Off (Ext Sensor)
To apply the output of current sensors that produce voltage, such as shunts and clamps, to an element’s external
current sensor input terminal (EXT) and perform measurements, set Ext Sensor to on.
External Current Sensor Range
Set the external current sensor range according to the output of the external current sensor.
The external current sensor range can be fixed (when auto range is set to off) or determined automatically (when
auto range is set to on).
Fixed Ranges
When the current range is fixed, you can select a range from the available options. The selected current range
does not change even if the amplitude of the input signal changes. Set the range in reference to the rms value of
the input signal.
760901 (30A High Accuracy Element), 760902 (5A High Accuracy Element)
• When the Crest Factor Is Set to CF3
Select from 50mV, 100mV, 200mV, 500mV, 1V, 2V, 5V, and 10V.
• When the Crest Factor Is Set to CF6 or CF6A
Select from 25mV, 50mV, 100mV, 250mV, 500mV, 1V, 2.5V, and 5V.
Auto range
This is the same as the auto range feature for voltage.
Click here.
