17-2
IM WT5000-01EN
Storage Device
This instrument can access the following three types of storage devices for saving and loading data.
Internal Memory (User)
The internal memory of this instrument.
USB Memory Device (USB−0/USB−1)
A USB memory device that is connected to the USB port of this instrument. USB2.0 mass storage devices
compatible with USB Mass Storage Class Ver. 1.1 can be connected to the instrument.
Network Drive (Network)
A storage device on the network. You can use a network storage device by connecting the instrument to an
Ethernet network.
Notes about Using USB Devices
• Connect the USB memory device to the USB port for peripherals (type A) directly, not through a USB hub.
• Use portable USB storage devices that are compatible with USB Mass Storage Class version 1.1.
• You cannot use protected USB storage devices (such as those that contain encrypted content).
• Only connect compatible USB keyboards, mouse devices, or memory devices to the USB ports for
peripherals.
• Do not connect and disconnect multiple USB devices repetitively. Provide at least a 10-second interval
between removal and connection.
• Do not connect or remove USB devices from the time when this instrument is turned on until key operation
becomes available (approximately 20 to 30 seconds).
• This instrument can handle up to two USB memory devices.
17 Saving Numeric Data, Waveform Data, and Screen Images
