If you do not set the trigger level properly, the waveform display start point (the signal level on the left edge of
the screen) may be unstable, or waveforms may not appear.
Display Group (Group)
Select the group you want to display from 1 to 4.
For each group, set the waveform you want to display using display item (Wave). For example, you can set
group 1 to display the inverter’s input waveform, group 2 to display the inverter’s output waveform, and group 3
to display the motor’s speed and torque.
If you change the display to split display in this condition, you can easily switch between observing the input
and output waveforms of the inverter and motor by changing the groups (1 to 3) displayed in the top and bottom
screens.
Display Items (Items, Wave)
All ON (All ON)
The waveforms of all input signals are displayed.
All OFF (All OFF)
No waveforms are displayed.
Display ON/OFF(Display ON/OFF)
• You can select whether to display the waveform of each input signal of each element by selecting or clearing
the signal’s check box. Only the input signals of installed elements appear.
• On models with the motor evaluation 1 or 2 option, you can turn the displays of the waveforms of the speed,
torque, and Aux input signals on and off.
Vertical Zoom (Vertical Zoom)
Each displayed waveform can be scaled. You can select one of the following zoom factors:
0.1, 0.2, 0.25, 0.4, 0.5, 0.75, 0.8, 1, 1.14, 1.25, 1.33, 1.41, 1.5, 1.6, 1.77, 2, 2.28, 2.66, 2.83, 3.2, 3.54, 4, 5, 8,
10, 12.5, 16, 20, 25, 40, 50, 100
11 Graph Display
