YOKOGAWA WT5000 Features Guide

1-4
IM WT5000-01EN
Harmonic Measurement Function Orders
The harmonic orders that you can specify are indicated below.
Input Element Harmonic Measurement Functions
Measurement
Function
Characters or Numbers in Parentheses
Total Value 0(DC) 1 k
U( ) Yes Yes Yes 2 to 500
I( ) Yes Yes Yes 2 to 500
P( ) Yes Yes Yes 2 to 500
S( ) Yes Yes Yes 2 to 100
Q( ) Ye s Always zero Yes 2 to 100
λ( ) Ye s Ye s Ye s 2 to 100
Φ( ) Yes No Ye s 2 to 500
ΦU( ) No No No 2 to 500
ΦI( ) No No No 2 to 500
Z( ) No Yes Yes 2 to 100
Rs( ) No Yes Yes 2 to 100
Xs( ) No Yes Yes 2 to 100
Rp( ) No Yes Yes 2 to 100
Xp( ) No Yes Yes 2 to 100
Uhdf( ) No Yes Yes 2 to 500
Ihdf( ) No Yes Yes 2 to 500
Phdf( ) No Yes Yes 2 to 500
Uthd Yes No No No
Ithd Yes No No No
Pthd Yes No No No
Uthf Yes No No No
Ithf Ye s No No No
Utif Yes No No No
Itif Yes No No No
hvf Yes No No No
hcf Yes No No No
K-factor Yes No No No
Functions with parentheses will produce different values depending on which of the following is contained in their
parentheses.
• Total: Total value (The total value of all harmonic components from the minimum order to N.* For information
about how the value is determined, see appendix 12 in the Getting Started Guide, IM WT5000-03EN.)
• 0(DC): DC value
• 1: Fundamental harmonic value
• k: The value of any order from 2 to N.*
* N is the maximum measurable order. he maximum measurable harmonic order is the smallest of the three
orders listed below.
• The specified maximum measurable harmonic order
• The value determined automatically according to the PLL source frequency (see section 6.7 in the Getting
Started Guide, IM WT5000-03EN)
• When the data update interval is 50 ms or Auto, the maximum measurable harmonic order is 100.
1 Items That This Instrument Can Measure
