YOKOGAWA WT5000 Features Guide

16-12
IM WT5000-01EN
Single Shot (Single Shot)
Time
REC
key
State
REC
REC
Solid
CMPL
Storage count
PAUSE
Solid
END
key
Storage Operations Performed When Storage in Progress Is Paused
Restarting Storage
When you start recording, pause recording, and then start recording
Time
State
REC
REC
Solid
PAUSE
REC
key
PAUSE
Blinking
REC
key
PAUSE
key
REC
REC
Solid
Ending Storage
When you start recording, pause recording, and then end recording
Time
State
REC
REC
Solid
PAUSE
END
key
PAUSE
Blinking
REC
key
PAUSE
key
Storage Operation When the Storage Interval Is Not an Integer Multiple of the Data
Update Interval
Here we will use the case when the data update interval is 5 s and the storage interval is 7 s as an example.
How storage is performed varies as indicated below depending on the storage mode.
When the Storage Mode Is Not Set to Integration Synchronization
Storage is performed according to the storage interval.
Time [s]
Data
update
Storage
Time [s]
0 5 10 15 20 25 30 35
0 7 14 21 28 35
When the Storage Mode Is Integration Synchronization and the Integration Mode Is Not Continuous or
Real-Time Continuous
Storage is performed at the first data update after the storage interval passes.
Time [s]
Data
update
Storage
Time [s]
0 5 10 15 20 25 30 35
0 7 14 21 28 35
16 Data Storage

YOKOGAWA WT5000 Specifications

General

Frequency Range	DC, 0.1 Hz to 1 MHz
Number of Channels	Up to 7
Interfaces	USB, Ethernet, GP-IB, RS232
Sampling Rate	10 MS/s
Harmonic Analysis	Up to the 500th order
Weight	Approximately 15 kg
Display	10.1-inch WXGA (1280 x 800) TFT LCD
