List of Parameters
List of Parameters
STC Setting Display 1 (STC1)
Parameter Name Setting and Display Range Unit
Factory Default Value
Display and Setting Conditions
for Controller Mode
User
Set-
tings
YS1500
(SINGLE)
YS1700
(PROG)
SINGLE
CAS
SELECT
PROG
PV1 Process variable 1 Equivalent to -6.3 to 106.3% in the engineering unit (Note 1) Engineering Unit Undefined R R R R
SV1 Setpoint value 1 Equivalent to -6.3 to 106.3% in the engineering unit (Note 1) Engineering Unit 0.0 R/W R/W R/W R/W
MV1 Manipulated output variable 1 (Note 2) -6.3 to 106.3 % -6.3 R R R R
STC STC mode selection
OFF: STC is not operating DISP: STC values displayed only
ON: STC is operating ATSTUP: STC automatic start-up (Note 3)
OFF R/W R/W R/W R/W
OD On-demand tuning start OFF, ON OFF R/W R/W R/W R/W
PB1 Proportional band 1 0.1 to 999.9 % 999.9 R/W R/W R/W R/W
TI1 Integral time 1 1 to 9999 s (second) 1000 R/W R/W R/W R/W
TD1 Derivative time 1 0 to 9999(0: OFF) s (second) 0 R/W R/W R/W R/W
IP1 Process type 1
STATIC: Static process
DYNAM: Astatic process (with integral characteristics)
STATIC R/W R/W R/W R/W
TR1 Process response time 1 4 to 9999 s (second) 300 R/W R/W R/W R/W
NB1 Noise band 1 Equivalent to 0.0 to 20.0% in the engineering unit (Note 1) Engineering Unit 0.0 R/W R/W R/W R/W
OS1 Control target type 1
ZERO: Overshoot zero
MIN: Overshoot: Small (About 5%) Settling time: Short
MED: Overshoot: (About 10%) Rise time: Medium-fast
MAX: Overshoot: (About 15%) Rise time: Fast
MED R/W R/W R/W R/W
MI1 MV applied signal span 1 0.0 to 20.0 % 5.0 R/W R/W R/W R/W
PMX1 High limit setpoint of proportional band 1 2.0 to 999.9 % 999.9 R/W R/W R/W R/W
PMN1 Low limit setpoint of proportional band 1 2.0 to 999.9 % 2.0 R/W R/W R/W R/W
IMX1 High limit setpoint of integral time 1 1 to 9999 s (second) 9999 R/W R/W R/W R/W
IMN1 Low limit setpoint of integral time 1 to 9999 s (second) 1 R/W R/W R/W R/W
DMX1 High limit setpoint of derivative time 1 0 to 9999 s (second) 2000 R/W R/W R/W R/W
PA1 Calculated proportional band 1 2.0 to 999.9 % 999.9 R R R R
IA1 Calculated integral time 1 1 to 9999 s (second) 1000 R R R R
DA1 Calculated derivative time 1 0 to 9999 s (second) 0 R R R R
CR1 Presumed accuracy error 1 0.00 to 99.99 % 0.00 R R R R
RT1 Signal distribution ratio 1 0.000 to 9.999 1.000 R R R R
LM1 Equivalent dead time 1 0 to 9999 s (second) 0 R R R R
TM1 Equivalent lag time 1 0 to 9999 s (second) 0 R R R R
GM1 Equivalent process gain 1 0.000 to 9.999 0.000 R R R R
Note 1: The engineering units set with the Engineering parameters, SCH1, SCL1, and SCDP1.
Note 2: MV (Manipulated output variable) can be set only with the MV operation key at the bottom of the front panel. MV will be displayed when the controller mode is set to cascade or selector.
Note 3: ATSTUP can not be set if the controller mode is set to the selector or the selector control module is being used in the programmable mode.
