Yolin YL81F - 6.4 Setting Wheel Diameter; 6.5 Setting Speed Sensor Magnets

10
6.4 Wheel diameter setting
04P is the wheel diameter setting. The adjustable wheel diameter range is: 8~50inch.
Press to enter the parameter changing state. Press the / to select the parameter and press to save the
parameter setting and return to the personalized parameter setting interface.
Figure 6-5 Wheel diameter setting interface
6.5 Number of speed sensor magnets setting
05P is the speed sensor magnet number setting. The adjustable speed sensor magnet number range is: 1 ~ 15 pcs （5S
protocol）,1 ~ 63 pcs （KDS protocol）.
Press to enter the parameter changing state. Press the / to select the parameter and press to save the
parameter setting and return to the personalized parameter setting interface.
Figure 6-6 Number of speed sensor magnets setting interface
