Yolin YL81F - Reference Schedules; Error Code Definitions; Pedal Assist Level Ratio Values

18
Schedule 1: Error Code Definition
YL-01, YL-02 Error codes
Error code
Definition
Error code
Definition
E001
Controller failure
E004
Throttle failure
E002
Communication failure
breakdown
E005
Brake failure
E003
Hall failure
E006
Motor phase failure
YL-05, KDS, YL-J Error codes
Error code
Definition
Error code
Definition
E021
Current failure
E024
Hall failure
E022
Throttle failure
E025
Brake failure
E023
Motor phase failure
E030
Communication failure
breakdown
Schedule 2: Pedal Assist Level Default Ratio Value
Level
Level
selection
1
2
3
4
5
6
7
8
9
0-3/1-3
50%
74%
92%
-
-
-
-
-
-
0-5/ 1-5
50%
61%
73%
85%
96%
-
-
-
-
0-7/ 1-7
40%
50%
60%
70%
80%
90%
96%
-
-
0-9/ 1-9
25%
34%
43%
52%
61%
70%
79%
88%
96%
