Page #15 background image
FORM 160.73-N1 (904)
15
YORK INTERNATIONAL
TABLE 2 – APPROXIMATE UNIT WEIGHT INCLUDING MOTOR*
* Refer to product drawings for detailed weight information.
SHELLS
COMPRESSOR
SHIPPING OPERATING EST. REFRIGERANT
WEIGHT (KG) WEIGHT (KG) CHARGE (KG)
A-A P1, P2, P3, P4 6,005 7,470 568
B-B P1, P2, P3, P4 6,730 8,560 704
C-C P5, P6, P7, Q7 8,270 10,330 727
D-D P6, P7, Q7 9,845 12,425 863
E-E P8 9,208 10,886 794
F-F P8, P9 10,478 12,610 1,057
G-G P8, P9 10,886 13,018 930
H-H P8, P9 12,428 15,195 1,225
E-E H5 10,370 12,645 768
E-F H5 11,055 13,590 813
F-E H5 10,840 13,290 863
F-F H5, H6 11,520 14,240 918
F-G H5, H6 12,605 15,710 977
G-F H3, H5, H6, H7, H8 12,670 15,775 1,040
G-G H3, H5, H6, H7, H8 13,750 17,235 1,097
G-G J1, J2 13,340 16,715 1,097
G-H J1, J2 13,915 17,550 1,163
H-G H3, H5, H6, H7, H8 14,705 18,450 1,163
H-G J1, J2 14,465 18,210 1,193
H-H J1, J2 15,045 19,075 1,284
H-H J3 15,595 19,625 1,284
H-J J1, J2 16,135 20,625 1,368
H-J J3 16,685 21,175 1,368
J-H J1, J2 16,635 21,265 1,504
J-H J3 17,185 21,815 1,504
J-J J1, J2 17,725 22,815 1,588
J-J J3, J4 18,275 23,365 1,588
T-T J1, J2 19,305 25,010 1,815
T-T J3, J4 19,855 25,560 1,815
T-V J3, J4 21,525 27,950 1,950
V-T J3, J4 20,360 26,270 1,736
V-V J3, J4 22,030 28,675 1,886
W-V J3, J4 24,145 31,575 2,027
X-X J5 30,430 39,350 2,635
