York YVWA - FIGURE 2 - YVWA Chiller Major Components (Front View)

JOHNSON CONTROLS
16
FORM 201.30-ICOM1 (519)
ISSUE DATE: 05/22/2019
SECTION 2 - PRODUCT DESCRIPTION
1
2
3
FIGURE 2 - YVWA CHILLER MAJOR COMPONENTS (FRONT VIEW)
LD17364
1. Control Panel
2. Variable Speed Drive (VSD)
3. Oil Separator
4. Return Water Box
5. Condenser
6. Condenser Sight Glass
7. Evaporator
8. Condenser Water Nozzle
4
5
6
8
7
