York YVWA - TABLE 4 - Torque Specification

JOHNSON CONTROLS
32
FORM 201.30-ICOM1 (519)
ISSUE DATE: 05/22/2019
SECTION 3 - HANDLING, STORAGE, INSTALLATION AND REASSEMBLY
TABLE 4 - TORQUE SPECIFICATION
UNIT
ITEM DESCRIPTION
YORK PART
NUMBER
SAP
NUMBER
QUANTITY
TORQUE VALUE
FT-LBS. N-M
END SHEETS (CON-EVAP ASSY)
A - HCS5 0.625-11 X 2.500 GR 5 ZN 021-32010-020 616904 8 154 209
HEAT EXCHANGER PIPING
B 24 HCS5 0.500-13 X 2.000 GR 5 ZN 021-32008-503 847455 8 50 68
COMPRESSOR MOUNTING
C 21 HCS5 0.750-10 X 2.500 GR 5 ZN 021-32012-501 616916 8 50 68
D 18 HCS5 0.375-16 X 2.500 GR 5 ZN 021-32006-020 730823 4 50 68
COMPRESSOR PIPING
E 36 HCS5 0.375-16 X 1.500 GR 5 ZN 021-32006-012 730819 10 50 68
F 13 HCS5 0.625-11 X 3.000 GR 5 ZN 021-32010-024 616905 4 50 68
H
30 Elbow 3/4 O.D.Tube 90 Deg Male 023-21937-000 146081
Refer to Table 11 on page 47 and
Table 12 on page 47 for
Torque Specications
94 Tee UNF(F) 0.750in UNF(F) 0.750in UNF 023-25549-000 827494
J 31 Elbow 1/2 O.D.Tube 90 Deg Male 023-18982-000 146248
OIL SEPARATOR MOUNTING
P 18 HCS5 0.375-16 X 2.500 Gr 5 Zn 021-32006-020 730823 4 50 68
OIL SEPARATOR PIPING
G 24 HCS5 0.625-11 X 3.000 GR 5 ZN 021-32010-024 616905 8 50 68
O 31 Elbow 1/2 O.D.Tube 90 Deg Male 023-18982-000 146248
Refer to Table 11 on page 47 and
Table 12 on page 47 for
Torque Specications
R 10 HCS5 0.750-10 x 4 GR5 Zn 021-32012-032 730852 8 135 185
LIQUID INJECTION PIPING
K 22 Elbow 3/8 O.D.Tube 90 Deg Male 023-18981-000 146247 Refer to Table 11 on page 47 and
Table 12 on page 47 for
Torque Specications
L 51 Nut 3/8 O.D. Tube 023-18977-000 146243
EDUCTOR PIPING
M 23 Adapter Straight 1 -14 Un-2B 023-19030-000 146209 Refer to Table 11 on page 47 and
Table 12 on page 47 for
Torque Specications
N 47 Sleeve 3/4 O.D. Tube 023-18284-000 146273
ENCLOSURE MOUNTING
Q 8 HCS5 0.375-16 X 1.500 GR 5 ZN 021-32006-012 730819 8 50 68
