SECTION 3 - HANDLING, STORAGE, INSTALLATION AND REASSEMBLY
LIFTING WEIGHTS
A lifting diagram is placed on the chiller and the shipping package. For detailed unit weights and weight distribu-
tion, refer to the data shipped in the chiller information packet and unit nameplate.
TABLE 1 - UNIT WEIGHT
APPROXIMATE UNIT WEIGHT
COMPRESSOR
CODE
9,10)
SHELL
CODE
(PIN 5,7)
SHIPPING
WEIGHT RANGE
MIN - MAX
OPERATING
WEIGHT RANGE
MIN - MAX
REFRIGERANT
CHARGE RANGE
MIN - MAX
LOADING PER
ISOLATOR
MIN - MAX
LBS KG LBS KG LBS KG LBS KG
FX
B-B
7694-
8329
3490-
3778
8254-
8995
3744-
4080
276-298 125-135
2064-
2249
936-1020
C-C
8263-
8519
3748-
3864
8915-
9306
4044-
4221
331-353 150-160
2229-
2326
1011-
1055
D-D
8922-
9228
4047-
4186
9667-
10135
4385-
4597
386-408 175-185
2416-
2533
1096-
1149
GX
B-B
7981-
8616
3620-
3908
8541-
9281
3874-
4210
298-320 135-145
2134-
2321
968-1053
C-C
8549-
8805
3878-
3994
9202-
9592
4174-
4351
353-375 160-170
2299-
2399
1043-
1088
D-D
9209-
9515
4177-
4316
9954-
10421
4515-
4727
408-430 185-195
2489-
2606
1129-
1182
NOTE: Weights shown for base unit; selected options and tube count variations may add weights and/or refrigerant charge quantity to unit.
Contact your nearest Johnson Controls Sales Ofce for weight data.
