2
Temperature: 5 ℃-40 ℃;
Power supply: AC220V, 50Hz;
Ground: The resistance to ground should be less than 5Ω;
The environment for the equipment should be dry, smokeless, dust-free, pollution-free, and shouldn’t have
vibration, strong current, strong magnetic field and other interferences.
Air pressure: 86-106kpa.
1.4 Equipment composition
CMA1325C-B-A laser cutting machine adopts modular design and consists of the frame, beams,
cutting head, worktable, console and auxiliary equipment, as shown below:
Fig.1-1 CMA1325C-B-A Laser Cutting Machine (refer to real machine)
1.4.1 Auxiliary equipment
In order to ensure the normal operation, the laser equipment also requires some auxiliary parts, such as fan
and chiller. Different models have different auxiliary parts, and the actual equipment shall prevail.
Fig.1-2 Auxiliary equipment
