Opening the Control Program (GUI)
When you click on the Zapco HDSP Heatsink icon you get the splash screen below. Notice the GUI version
number (here it is v.2.9.1) on the right side under DIGITAL CONTROL PROGRAM.
The HDSP Series is an evolving product and any number of features will be added as new technologies
become available. You will want to keep a regular eye out for updates at
zapco.com/hdsp-5-support
to
keep your HDSP current.
Before the GUI opens, you need to tell the program if you wish to open in
Connect via WIFI*
or
Connect via COM**
mode and which HDSP model you will be working with Select Device drop-down
menu. If you choose Connect via COM mode you will confirm the COM port number and you can click
START to open the GUI.
* Your HDSP processor can be controlled by PC or laptop through either the supplied USB connection or
by wireless connection. The initial connection must be by USB, then once the GUI is opened you can
enable the WiFi for future connections (see pag. 17 to enable WiFi).
** Different PCs can react differently to USB cables. If the supplied 5m cable does not allow immediate
connection (no COM port showed under Select COM, you should try a 2m USB cable.
15
