zapco HDSP-V Series - Technical Specifications

Technical Specifications
DSP Processor OMAP L-138 - 2 x 456 MHz - 32 Bit (till 64-bit / IEEE double precision)
Processor Point: Fixed & Floating
Sampling Rate: 96 KHz (HDSP-Z16V), 192 KHz (HDSP-Z8V)
Player Power 456 Mhz - Arm 9 32 Bit
Audio Formats WAV, AIF, AIFF, FLAC, ALAC, AAC, MP3
ADC Standard: AK5558, 32 Bit, 784 KHz, DR 115 dB
Option B: AK5578, 32 Bit, 784 KHz, DR 121 dB
DAC Standard: AK4458, 32 Bit, 784 KHz, DR 115 dB (*8ch)
Option B: AK4490, 32 Bit 784 KHz, DR 120 dB (*8ch)
Option A: ES9038PRO, 32 Bit, 784 KHz, DR 132 dB (*8ch)
S/N Floor Noise -125 dB (from 20 Hz to 20 KHz)
-135 dB (from 150 Hz to 20 KHz)
-140 dB (average from 80 Hz to 20 KHz)
Crosstalk 100 Hz/100 dB - 1 KHz/115 dB - 10 KHz/100 dB (average all channels)
Frequency Response 5Hz @ 45 KHz (HDSP-Z16V), 5Hz @ 90 KHz (HDSP-Z8V)
Analog IN 6/8 x RCA Low Level 1/5 Volt RMS, 5KOhm, Gain Control, Clipping LED
8 x High Level 4/20 Volt, 200 Ohm, Gain Control, Clipping LED
S/N Ratio: from 109 to 115 dB A
THD+N: 0,001, 1V Out (HDSP-Z16V), 0,0008, 1V Out (HDSP-Z8V)
Digital IN Optical: 24 Bit - 192 KHz
SPDIF: 24 Bit - 192 KHz
3 x i2S: 24 Bit - 192 KHz
S/N Ratio: from 115 to 120 dB A
THD+N: 0,0008 (HDSP-Z16V), 0,0006 (HDSP-Z8V)
Analog OUT 16 x RCA (HDSP-Z16V), 8 x RCA (HDSP-Z8V), 4 Volt RMS
Equalizer Parametric 30/6 poles (HDSP-Z16V), 15 poles (HDSP-Z8V)
Phase Filter All channels 1Hz/1 Degree step
VSEQ Filter 50-200 Hz - 1 Hz step
Dash Board 3" Double speed Touch Screen, Resolution 240 x 400 px, cable 5 mt
Controls: HDPlayer/Volume/Balance/Fader/Tone/Presets
Wireless Wi-Fi External Module (included), cable 1 mt
External aptX HD Module (optional, Qualcom CSR8675)
Connections PC/Dash Board: USB-B / RJ45
USB (Audio) Memory stick formatted FAT32, with a limited space memory of 2 TB
Power Supply Operating: 6-16 Volt, Stop-Start ignition system support, Fuse 1A
Dimensions (mm) Main Unit: 217(L) x 164(W) x 57(H), Dash Board: 111(L) x 16(W) x 49(H)
